How to Turn a Pioneer50 Forklift into an Off-Road Mini Crane

How to Turn a Pioneer50 Forklift into an Off-Road Mini Crane

A photo of a blue Pioneer50 forklift that has been modified into an off-road mini crane with a red boom and four yellow support legs. The mini crane is lifting a large blue container on a green field with the kaystar factory  in the background.

The Pioneer50 is a four-wheel drive all-terrain forklift that is specially designed for mining and construction sites. It has four-wheel steering, solid rubber tires, and a rated load of 5 tons. It is equipped with a three-stage free lift mast, a customized enclosed cab, and a side shifter. However, you can also modify this 5-ton diesel forklift by adding a boom and support legs, and turn it into an off-road mini crane. Here is how you can do it and what are the benefits of this transformation.

Step 1: Install the boom and support legs


The first step is to install the boom and support legs on the forklift. The boom is a telescopic arm that can extend and retract to adjust the lifting height and radius. The support legs are hydraulic jacks that can stabilize the forklift when lifting heavy loads. You can choose the size and capacity of the boom and support legs according to your needs, but make sure they are compatible with the forklift’s structure and power.

To install the boom, you need to remove the original fork carriage and attach the boom to the mast. You also need to connect the hydraulic hoses and electrical wires from the boom to the forklift’s system. To install the support legs, you need to mount them on the front and rear of the forklift’s chassis. You also need to connect the hydraulic hoses from the support legs to the forklift’s system.

Step 2: Test the performance and safety of the mini crane


The second step is to test the performance and safety of the mini crane. You need to check if the boom and support legs work properly and smoothly, and if there are any leaks or malfunctions in the hydraulic system. You also need to check if the mini crane can lift and move loads safely and efficiently, without tipping over or losing balance.

To test the performance, you can use a load chart that shows the maximum load capacity of the mini crane at different heights and distances. You can also use a hook monitoring system that displays the load weight, angle, and position on a screen in the cab. To test the safety, you can use a load moment indicator that warns you if the load exceeds the stability limit of the mini crane. You can also use a slew limiter that prevents you from rotating the boom beyond a certain angle.

Step 3: Enjoy the advantages of the mini crane


The third step is to enjoy the advantages of the mini crane. By transforming your Pioneer50 forklift into an off-road mini crane, you can gain more versatility and functionality for your work. You can use the mini crane to lift and transport materials that are too heavy or bulky for a regular forklift, such as steel beams, concrete blocks, pipes, or containers. You can also use the mini crane to work on uneven or rough terrain, such as hills, fields, or mountains, where a regular forklift would struggle or get stuck.

The mini crane also has some features that make it more convenient and comfortable than a regular forklift. For example, you can use the side shifter to adjust the position of the load without moving the whole vehicle. You can also use the enclosed cab to protect yourself from dust, noise, or weather conditions. Moreover, you can use the four-wheel steering to maneuver in tight spaces or turn around easily.
